T-Rex XL360 Series II 12V Telescopic Electric Hoist 800kg Swivel Crane

The T-Rex XL360 Series II Telescopic Electric Hoist is a versatile 12V lifting crane for utes, trucks, trailers and workshop use. With up to 800kg double-rope capacity, a 2m lift and 360-degree manual rotation, it makes loading, unloading and engine lifting safer and easier.

Key Features

• Built from high quality carbon steel with a hard-wearing powder-coated finish
• T-Rex Gorilla winch gearset for safe loading, unloading and heavy load handling
• Inbuilt overload protection disables operation if the load exceeds maximum capacity
• Single-handed operation via the 10' dual control, leaving one hand free to guide the load
• Extra-high 2m lift suitable for a wide range of jobs
• 3-tier boom with 3 secure telescopic settings
• 360-degree continuous manual rotation with brake to load and unload in any direction
• Compact fold design that is easy to install
• Suitable for mounting on trucks, utes, trailers, pontoons and most similar structures
• Can be mounted on commercial vehicles for loading and unloading freight
• Operates on a 12V battery power source

Specifications

• Manufacturer: T-Rex
• Model: XL360 Series II
• Power input: 12V DC 125 Amps
• Lifting capacity (max): 500kg single-rope / 800kg double-rope
• Overload protection: disables operation with 30 second re-start
• Lifting height (base to hook): 2m
• Reach (max): 1.44m
• Rotation (continuous) with brake: 360 manual
• Lifting cable: 4.8mm x 4.5m (single-rope), 4.8mm x 5.5m (double-rope)
• Line speed with no load: 3.6m/min (single-rope)
• Switch cable length: 6.6m
• Product weight: 56.3kg
• Product dimensions (W x L x H): 25.2 x 167 x 120cm
• Carton weight: 64kg
• Carton dimensions (W x L x H): 30 x 127 x 33cm
• Requires high tensile bolts to fasten the engine hoist (not supplied)
• Minimal assembly required

What's in the Box

• 1 x T-Rex Telescopic Engine Hoist
• 1 x Remote
• 1 x User Manual
