Baumr-AG Hercules HDS800 65 Ton Diesel Log Splitter 6HP 296cc

The Baumr-AG Hercules HDS800 is a heavy-duty 65 ton diesel log splitter built to take on tough Australian hardwoods like Gum and Ironbark. With a 6HP four-stroke diesel engine and a two-stage hydraulic pump, it splits in both horizontal and vertical positions so you can work through large logs without lifting them onto the machine.

Key Features

• Powerful 65 ton tested splitting force (43 ton rated) for demanding hardwood
• Horizontal and vertical splitting positions to handle heavy logs with less lifting
• Removable working table for extra working room and storage, and for a slimmer profile when stored
• Removable 4-way head splits a log into four pieces, mounted without fixed bolts for quick wedge interchange
• Patented DirectDrive transfers power from the diesel four-stroke engine with no vibration and no required servicing
• Heavy-duty fixed stripper removes wood stuck to the wedge on the return cycle
• Proper Australian (non-US type) 50mm trailer coupling
• Extra-large quick-release fold-away jockey wheel with integrated dual-action foot-activated brake to prevent rolling or pivoting
• Two genuine Benmar hydraulic hoses with patented HoseGuard spiral protection to hold their shape and add protection when towing
• Oversized oil filter to help protect against particle contamination, with replacements available at auto accessory retailers
• 16 inch extra-wide pneumatic tyres with bearings for transport over varied terrain

Specifications

• Brand: Baumr-AG
• Model: Hercules HDS800
• Type: Log splitter
• Power source: Diesel
• Starting system: Recoil
• Output: 6HP
• Displacement: 296cc
• Fuel type: Diesel
• Fuel tank capacity: 6.5L
• Engine oil type: 10W-30 / 10W-40 / 15W-30 / 15W-40 non-synthetic engine oil (not included)
• Engine oil capacity: 1.1L
• Pump type: 16GPM two-stage
• Hydraulic hose: Benmar
• Hydraulic oil capacity: 22L
• Hydraulic oil type: 10WT AW32, ASLE H-150 or ISO32
• Max. splitting length: 550mm*
• Max. tested splitting force: 65 tons
• Rated splitting force: 43 tons
• Max. ram travel: 495mm*
• Diameter of ram: 140mm*
• Cycle time: 18s
• Wheel diameter: 16 inches pneumatic with bearing
• Jockey wheel diameter: 8 inches
• Product dimensions (L x W x H): 223 x 110 x 171cm
• Product weight: 300kg
• Carton dimensions (L x W x H): 193 x 49 x 83cm
• Carton weight: 330kg

What's in the Box

• 1x Baumr-AG HDS800 Log Splitter
• User manual is accessible online

SKU: LGSDSLBMRA8D0
