Wurth 1/2 Inch Torque Wrench 40-200Nm Ratchet Drive

This Wurth 1/2 inch torque wrench delivers precise bolt tightening across a 40-200 Nm range, making it a dependable tool for professional and enthusiast use. Its 72-tooth ratchet head and large dual scale support accurate, controlled work on right-hand and left-hand threads.

Key Features

• High trigger accuracy of ±3%, surpassing standard requirements
• Large double scale in Nm and lbf-ft for easy reading of torque settings
• Torque adjustment by twisting the end of the handle
• Locking knob securely locks and unlocks set values
• Ergonomic, non-slip 2C handle for comfort and efficient power transmission
• Suitable for clockwise and anti-clockwise tightening, for use on right-hand and left-hand threads
• Moisture- and oil-resistant packaging made from 100% post-consumer recycled plastic
• ISO 6789-1 compliant

Specifications

• Tip size: 1/2 inch
• Torque measuring range: 40-200 Nm (30-146 lbf-ft)
• Accuracy: ±3%
• Teeth: 72, with a 5-degree rotation angle for precise positioning
• Total length (L1): 488 mm
• Lever length (L2): 395 mm
• Handle length (L3): 167 mm
• Ratchet head height (B1): 24 mm
• Head height with square (B2): 39 mm
• Handle diameter (D1): 37 mm
• Ratchet head width (D2): 45 mm

Calibration

For peace of mind and optimal performance, regular calibration is recommended every 12 months or after 5,000 tightening operations.
