Simplecom EC318v2 PCIe x4 to USB 3.2 Gen 2x2 20Gbps USB-C Expansion Card

Add a high-speed USB-C port to your desktop PC with the Simplecom EC318v2 PCIe x4 to USB 3.2 Gen 2x2 expansion card. Delivering data transfer rates of up to 20Gbps through a single USB-C port, it is a practical upgrade for modern devices that need maximum performance.

Key Features

• PCIe x4 expansion card, also compatible with PCIe x8 or x16 slots
• USB 3.2 Gen 2x2 interface supports data transfer rates of up to 20Gbps
• Adds 1x USB-C 20Gbps port to your desktop PC
• Backward compatible with USB 3.2 Gen 1, Gen 2 and earlier devices
• Built-in overcurrent protection
• Powered by PCIe, no external power required
• Integrated PCIe 12V to 5V module provides power to the USB ports
• Plug and play with automatic installation on Windows

Specifications

• PCIe Interface: PCIe 3.0 x4 (compatible with PCIe x8 or x16 slot)
• USB Standard: USB 3.2 Gen 2x2 20Gbps
• Connectors: 1x USB-C
• USB Speed Support: 20Gbps, 10Gbps, 5Gbps, 480Mbps
• USB Power Source: Integrated PCIe 12V to 5V module, SATA 15Pin (backup power only)
• Operating System Support: Windows 8 and above

What's in the Box

• 1x USB 3.2 Gen 2x2 1-Port PCIe x4 Card
• 1x low profile bracket

Important Notes

• The EC318v2 does not support DP Alt Mode or USB-C Power Delivery.
• The EC318v2 is designed for PCIe 3.0 interfaces. To achieve the full speed of USB 3.2 Gen 2x2, use a PCIe slot based on PCI Express 3.0 or a newer version on your motherboard.
• Actual data transfer speeds may be limited by the connected USB device. Check your USB device's maximum supported speed.
• Thunderbolt 3 devices are supported but are only compatible with a 10Gbps data transfer rate.
• Windows 7 is not supported.
