Name: mbeat Elite X14 USB-C Hub with Triple 4K Display, 100W PD and Gigabit Ethernet
Brand: mbeat
SKU: V186-MB-UCD-X14
Price: 171.60 AUD
Availability: InStock

The mbeat Elite X14 Multi-Port USB-C Hub expands a single USB-C connection into a full workstation setup, supporting up to three external 4K displays plus high-speed data, wired networking and audio. It is a comprehensive connectivity solution for laptops, content creators and professionals who need more ports without extra adapters.

Key Features

Triple 4K display support via two HDMI ports and one DisplayPort
USB-A 3.2 Gen 1 and USB-C 3.2 Gen 1 data ports offering up to 5Gbps transfer speeds
Three USB-A 2.0 ports for legacy devices such as keyboards, mice and peripherals
Integrated SD and MicroSD card reader for quick access to media files
RJ45 port supporting 10/100/1000M Gigabit Ethernet for stable wired internet
PD3.0 pass-through charging up to 100W to keep your laptop powered while using other hub functions
Built-in 3.5mm audio jack supporting microphone and audio input
Thunderbolt 3 port compatible

Specifications

Host Interface: USB-C 3.2 Gen 2, supports USB-C DisplayPort 1.4 (DP-Alt Mode)
HDMI Ports: HDMI 2.0 x2, max. resolution 4K/60Hz
DisplayPort: DP 1.4 x1, max. resolution 4K/144Hz
USB-A Data Ports: USB 3.2 Gen 1 x2 (max. 5Gbps); USB 2.0 x3 (max. 480Mbps)
USB-C Data Port: USB-C 3.2 Gen 1 x1, max. 5Gbps
USB-C PD Port: PD 3.0 x1, max. 100W (5V~20V/5A); USB-C PD charger not included
LAN Port: RJ45 x1, Gigabit Ethernet (10/100/1000Mbps)
Audio Port: 3.5mm x1, audio in/out
SD Slot: SD 2.0 x1, max. write speed 10MB/s, read speed 18MB/s
MicroSD Slot: MicroSD 2.0 x1, max. write speed 10MB/s, read speed 18MB/s
Compatible OS: Windows 10 and 11, macOS, iOS, Android
Compatible Devices: Most popular USB-C enabled laptops including Apple MacBook Air, MacBook Pro, Huawei MateBook, Lenovo, Xiaomi, Asus, Dell and HP notebooks, plus Huawei Mate10 and other USB-C devices

Display Configuration

Windows (USB-C DP-Alt DP1.4): Single display max. 4K/60Hz (HDMI 1/2) or 4K/144Hz (DP); dual display max. 4K/60Hz (HDMI 1/2 and DP); triple display max. 4K/60Hz (HDMI 1), 4K/30Hz (HDMI 2), 4K/60Hz (DP)
Windows (USB-C DP-Alt DP1.2): Single display max. 4K/30Hz (HDMI 1/2 and DP); dual display max. 1080p/60Hz (HDMI 1/2 and DP); triple display max. 1080p/60Hz (HDMI 1/2), 1080p/30Hz (DP)
macOS (USB-C DP-Alt DP1.4): Single display max. 4K/60Hz (HDMI 1/2) or 4K/144Hz (DP); dual display max. 4K/60Hz (HDMI 1/2 and DP); triple display max. 4K/60Hz (HDMI 1/2 and DP)
macOS (USB-C DP-Alt DP1.2): Single, dual and triple display max. 4K/30Hz (HDMI 1/2 and DP)

Note: Windows laptops support MST (Multi-Stream Transport), allowing two external monitors to display different content. macOS laptops only support SST (Single-Stream Transport) in USB-C DisplayPort (DP Alt-mode). MacBooks with M1, M2 and M3 CPUs currently support only one external monitor; connecting two external monitors will display duplicated content.
