Baumr-AG 65 Tonne Petrol Hydraulic Log Splitter with Detachable 4-Way Wedge HPS800

The Baumr-AG Hercules HPS800 MkII is a 65 tonne petrol hydraulic log splitter built for tough Australian hardwoods, splitting in both horizontal and vertical positions so heavy logs don't need to be lifted. Its detachable 4-way wedge quarters logs in a single pass, and the towable design with all-terrain tyres lets you work just about anywhere on your property.

Key Features

• Horizontal and vertical splitting positions to avoid lifting heavy logs
• Removable 4-way wedge splits four timbers from one log, uniquely mounted with no fixed bolts for quick wedge interchange
• Removable working table provides room and storage for multiple timbers, and slims the unit for storage
• Patented DirectDrive transfers power for maximum efficiency, no vibration and no required servicing
• 16 inch extra wide all-terrain rubber tyres for transportable use across varied terrain
• Proper Australian (non US type) 50mm trailer coupling
• Heavy-duty fixed stripper removes wood stuck to the wedge on the return cycle
• Extra-large quick-release fold-away jockey wheel with integrated dual-action foot-activated brake to prevent rolling or pivoting
• Two genuine Benmar hydraulic hoses encapsulated by patented HoseGuard spiral system to keep shape and add protection when towing
• Oversized oil filter protects the ram from particle contamination and is easy to replace at any auto accessory retailer

Specifications

• Brand: Baumr-AG
• Model: Hercules HPS800 MkII
• Engine: 18HP OHV 4-stroke
• Output: 18HP
• Starting System: Recoil
• Power Source: Petrol
• Type: Log Splitter
• Fuel Tank Capacity: 6.5L
• Fuel Type: Petrol
• Engine Oil Capacity: 1.1L
• Engine Oil Type: 10W-30 / 10W-40 / 15W-30 / 15W-40 non-synthetic engine oil (not included)
• Pump Type: 16GPM Two-Stage
• Hydraulic Hose: Benmar
• Hydraulic Oil Capacity: 22L
• Hydraulic Oil Type: 10WT AW32, ASLE H-150 or ISO32
• Max. Splitting Length: 550mm
• Max. Tested Splitting Force: 65 tons
• Rated Splitting Force: 43 tons
• Max. Ram Travel: 495mm
• Diameter of Ram: 140mm
• Cycle Time: 18s
• Wheel Diameter: 8 inches pneumatic with bearing
• Jockey Wheel Diameter: 8 inches
• Product Dimensions (L x W x H): 223 x 110 x 171cm
• Carton Dimensions (L x W x H): 193 x 49 x 74cm
• Carton Weight: 330kg

What's in the Box

• 1 x Baumr-AG HPS800 MkII Log Splitter
• 1 x Container of hydraulic fluid
• Note: User Manual is accessible online
