Philips HeartStart HS1 AED Defibrillator with Carry Case and Adult Pads

The Philips HeartStart HS1 AED is a user-friendly automated external defibrillator designed to help untrained or minimally trained responders treat suspected sudden cardiac arrest. With clear voice coaching and step-by-step guidance, it supports pad placement, CPR and shock delivery when needed.

Key Features

• Voice coaching provides easy-to-follow instructions from pad placement through to CPR and defibrillation
• Simple to learn and operate for first aiders with minimal training
• Comprehensive automatic self-tests check vital functions on a daily, weekly and monthly schedule
• SMART Pads cartridge with clear illustrated pad placement
• Quick Shock delivers a shock after a CPR interval, typically in eight seconds
• Adult and infant/child CPR guidance available at user selection

Specifications

• Model: Philips HeartStart Defibrillator M5066AABU
• Battery type: 9 volt DC, 4.2 Ah, disposable long-life lithium manganese dioxide primary cells
• Battery capacity: minimum 200 shocks or 4 hours of operating time (EN60601-2-4:2003)
• Battery install-by date: at least five years from date of manufacture
• Battery standby life: four years typical when installed by the install-by date
• Waveform: SMART truncated exponential biphasic, with parameters adjusted as a function of patient impedance
• Defibrillation peak current (adult): 32 A (150 J nominal) into a 50 ohm load
• Defibrillation peak current (paediatric): 19 A (50 J nominal) into a 50 ohm load using optional infant/child SMART Pads cartridge
• Shock-to-shock cycle time: typically less than 20 seconds between shocks in a series
• Shock delivery: via adhesive pads placed on the patient's bare skin as illustrated on the pads
• Controls: green SMART Pads cartridge handle, green on/off button, blue i-button, orange shock button
• Indicators: ready light, blue i-button, caution light

What's in the Box

• Defibrillator
• Adult pads
• Battery (one, pre-installed)
• SMART Pads (one set, pre-installed)
• Set-up and maintenance guide with expiration date tags
• Owner's manual
• Quick reference guide
• Standard carry case
