Baumr-AG 65cc Concrete Vibrator with 45mm Hard Nose Head

The Baumr-AG 65cc concrete vibrator is a portable petrol-powered tool that settles concrete quickly and evenly, helping remove air bubbles in beams, walls, forms and tight corners. With a 45mm hard-nose head and a balanced shaft, it gives you precise control over where the vibration goes.

Key Features

• Powerful 65cc engine producing up to 9,000RPM
• 45mm hard-nose head for precise placement in narrow forms and tight corners
• Balanced shaft and extra-wide ergonomic handle for comfortable handling
• Shoulder strap included to help manage the load on longer pours
• Easy recoil start
• Patented quick-connect coupling for easy separation and cleaning
• Super-lightweight design
• CDI ignition

Specifications

• Manufacturer: Baumr-AG
• Model: CVB760
• Displacement: 65cc
• Maximum engine speed: 9,000RPM
• Ignition type: CDI
• Attachment type: hard nose
• Head diameter: 45mm
• Frequency: 9,000Hz response
• Amplitude: 2.8mm output projection
• Fuel tank capacity: 1.2 litre
• Fuel mix: 25:1 (25 parts fuel to 1 part two-stroke oil)
• Fuel type: Regular Unleaded 95 +RON
• Certification: CE
• Product weight: 11kg
• Minimal assembly required

What's in the Box

• 1 x Baumr-AG CVB760 concrete vibrator
• 1 x 45mm hard nose
• 1 x Shoulder strap
• 1 x Tool kit
• User manual is accessible online

Carton Dimensions and Weight

• Carton A weight: 5kg
• Carton B weight: 8kg
• Carton A dimensions (W x D x H): 30 x 31 x 23cm
• Carton B dimensions (W x D x H): 15 x 108 x 12cm
